µRings SE

μRings SE is a resonator, transforming unpitched external excitation signals into pitched sounds by modeling the vibrations of bars, tubes, and strings.

This re-engineered Eurorack module updates and simplifies the classic Mutable Instruments Rings design by miniaturizing the module from 14HP to 8HP and redesigning the front panel layout without eliminating any original functionality.

Fully compatible with upstream Rings firmware. Includes power cable, mounting hardware, and a one-year warranty. Designed and built with care by Tall Dog Electronics in Western Massachusetts. Licensed CC BY-SA 4.0 open source hardware.

Manual PDF Flyer PDF

Part number Panel style Panel material
TD-URSE-B/B Matte black, gold markings Copper clad laminate
TD-URSE-B/S Satin silver, black markings Anodized aluminum
Height 3U (128.5 mm)
Width 8HP (40.3 mm)
Depth 43 mm (with power)
+12V 120 mA (average)
-12V 5 mA (average)
